C TILE
Thickness & Size
2.0mm X 304.8mm X 304.8mm
Contents per carton
50pcs
Weight per carton
19kgs
KẾT QUẢ KIỂM NGHIỆM
Subject
Result
Requirement
Thickness
1.92mm
2.0mm ± 0.15mm
Size width
304.81mm
304.8mm ± 0.30mm
Lenght
304.64mm
304.8mm ± 0.30mm
Squareness
0.05mm
Weight
3.9kgs/m2
-
Indentation 200 C
0.27mm
> / = 0.25mm
Indentation 450 C
0.48mm
Residual identation
3.2%
8%
Dimension stability bathed in hot air at 800 C , 6 hrs.
Width
0.05%
Lenght
0.02%
Volatile loss
0.10%
Slipperness
0.71 ( JIS A 5705 )
Abrasion
0.34mm ( JIS A 1451 )
